Timing Relays

Timing Relays for Industrial Automation

Timing relays are used in industrial automation systems to provide controlled delays, timed outputs, and sequencing functions in electrical control circuits. These relays are commonly installed in OEM machinery, industrial control panels, and plant-floor systems where repeatable timing logic is required to support safe and reliable machine operation.

In many control applications, timing relays are used to delay motor starts, sequence outputs, create interval timing functions, or manage machine states during startup and shutdown. Selecting the correct timing relay depends on the required timing function, time range, supply voltage, contact arrangement, and mounting style. Organizing timing relays by series helps maintenance teams and engineers identify compatible replacements quickly and maintain consistency with installed control panel designs.

Common applications

• On-delay and off-delay control logic
• Pump, fan, and motor start sequencing
• Machine interlocks and timed outputs
• OEM machinery and industrial control panels
• Maintenance replacement and spare inventory planning

Timing relay families

• 700T Timing Relays
• 700X Timing Relays
• 700Z Timing Relays

Related categories

• Motor Control & Protection
• Allen-Bradley

If you need help selecting the correct timing relay, verify the required timing function, time range, supply voltage, output contact arrangement, and mounting style before installation.
