Product Overview
Product Overview
Technical specifications for 100-A60NA31 Manufacturer Allen Bradley Product Type Contactor Product Line 100 Contactors Part Number 100-A60NA31 Weight 4.50 lbs (2.04 kg) Type Non-reversing Max Current 60 Amps 220V Rating (3-phase, 50 Hz) 15 kW 380V Rating (3-phase, 50 Hz) 30 kW 500V Rating (3-phase, 50 Hz) 37 kW 660V Rating (3-phase, 50 Hz) 37 kW 115V Rating (1-phase, 60 Hz) 5 Hp 230V Rating (1-phase, 60 Hz) 10 Hp 200V Rating (3-phase, 60 Hz) 20 Hp Coil Voltage 220V Poles 4 poles Request a Repair Description The 100-A60NA31 from Allen Bradley acts as a non-reversing contactor, suitable for a range of mechanical control tasks. It is specifically designed to handle a maximum current of 60 amps, ensuring it can manage substantial power demands. For operation at 220 volts in a three-phase configuration, this device can reach a power rating of up to 15 kW. It further accommodates 30 kW at 380 volts and can operate at a maximum of 37 kW for both 500 volts and 660 volts. In addition to its thr
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
