Technical specifications for 100-D115ZJ11L Manufacturer Allen Bradley Category PLCs Product Line IEC 100 Contactors Part Number 100-D115ZJ11L Weight 3.00 lbs (1.36 kg) Description DC-Operated Contactor Voltage Range 115 to 575 Volts AC Current Rating 115 Amps Coil Type Standard DC Conventional Coil Coil Voltage 24 Volts DC PLC Interface None Number of Poles 3 Terminal Type Bolt Type Auxiliary Contacts 1 Normally Open (NO) and 1 Normally Closed (NC) Protection Class IP 20 Request a Repair Description The 100-D115ZJ11L Bulletin 100-D large-frame IEC contactor from Allen-Bradley is designed for high current load applications. The 100-D115ZJ11L contactor has a rated carrying current capacity of 115 Amps at 400 Volts AC (AC-3) and 250 Amps at 690 Volts AC (AC-1). Only a 3-phase AC power source can be wired to the 100-D115ZJ11L contactor. It has an acceptable input voltage range between 115 Volts AC and 575 Volts AC (at 50 to 60 Hertz line frequency range). The 100-D115ZJ11L contactor is rat
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
