Product Overview
Product Overview
Allen-Bradley 1336F-A015-AN-EN-L6 is a Industrial Component used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
Application & Compatibility
The 1336F-A015-AN-EN-L6 Plus II Adjustable Frequency AC Drive is used for digital control of 3-phase induction motors in applications that need enhanced torque and speed control. The drive operates at an AC voltage range of 200 to 240V AC, and it has a drive power rating of 11kW (15HP), with variable torque input and output of 20KVA at 49A, and 19KVA at 48A. Its operating maximum heat dissipation is 205W, and it offers a displacement power factor of 0.98, with an efficiency of 97.5%. The 1336F-A015-AN-EN-L6 offers a maximum short circuit rating of 200,000A, with a BUS DC overvoltage and under voltage trips of 405V and 200V, respectively, and it provides microprocessor over temperature detection on the installed heatsink thermistor. The 1336F-A015-AN-EN-L6 provides a line transient protection of up to 6000V, and it uses an installed Metal Oxide Varistor (MOV) for voltage surge protection, and it provides phase-to-phase and phase-to-ground protection. It has the ability to ride through a short power interruption of 15 milliseconds at full load, and its logic control ride-thru time is 2 seconds. The 1336F-A015-AN-EN-L6, like all 1336 Plus II drives, offers a fully programmable Volt pe
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
