Product Overview
Product Overview
Allen-Bradley 1336F-A020-AA-EN-GMS5-L6 is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Power: 20 Horsepower
- Enclosure: NEMA Type 1
- Communication: DeviceNet
Application & Compatibility
The 1336F-A020-AA-EN-GMS5-L6 drive is a 1336 Plus II series variable frequency drive. It is designed by Allen-Bradley for industrial motor control applications. The drive can be used with compatible motors for a wide range of applications. The input voltage rating of the 1336F-A020-AA-EN-GMS5-L6 drive is 200 to 240 Volts AC. Input overvoltage and undervoltage protection is available on the drive, and the respective trip thresholds are 285 Volts AC and 138 Volts AC. The DC bus on the drive carries a nominal voltage rating of 324 Volts DC. The 1336F-A020-AA-EN-GMS5-L6 drive is configured to trip if the voltage on the DC bus crosses the preset high or low thresholds. The overvoltage trip threshold for the DC bus is 405 Volts DC and the undervoltage trip threshold is 200 Volts DC. The heatsink temperature on the 1336F-A020-AA-EN-GMS5-L6 drive is monitored by an on-board microprocessor. The Allen-Bradley 1336F-A020-AA-EN-GMS5-L6 1336 Plus II variable frequency drive can handle line transients of up to 6000 Volts. In constant torque mode, the drive can handle 150% of the rated output for 1 minute. In variable torque mode, the drive can handle 115% of the rated output for 1 minute. The ma
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
