Product Overview
Product Overview
Allen-Bradley 1336F-A020-AN-ES-L6 is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Power: 20 Horsepower
- Enclosure: Open
Application & Compatibility
The 1336F-A020-AN-ES-L6 drive is an Allen-Bradley 1336 PLUS II series variable frequency AC drive. It is available in an open enclosure with an IP 00 protection rating. This protection rating indicates that the drive enclosure does not provide any protection from solids or liquids. Therefore, the drive should not be used outdoors and it should be mounted inside a control cabinet indoors. The frame size of the drive is Size C. The weight of the AC drive is 38.6 kilograms and its dimensions are 27.6 x 11.88 x 3.68 inches. The total depth required for opening the back door of the drive is 5.18 inches. The 1336F-A020-AN-ES-L6 drive mounts vertically through 4 holes that are available on the enclosure. The minimum spacing recommendations for ensuring that the ambient temperature remains within the acceptable limits include 6 inches of vertical separation and 4 inches of horizontal separation between the drive and any adjacent equipment. The optimal ambient working temperature range for the Allen-Bradley 1336F-A020-AN-ES-L6 1336 PLUS II series variable frequency AC drive is from 0 to 50 degrees Celsius. The storage temperature range is from -40 to 70 degrees Celsius. The area where the d
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
