Product Overview
Product Overview
Allen-Bradley 1336F-A020-AN-FR is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Power: 20 Horsepower
- Enclosure: Open
Application & Compatibility
The Allen-Bradley 1336F-A020-AN-FR drive is a 1336 PLUS II series digital AC drive. It is designed for motor control applications. The control method supported by the drive is sine-coded pulse-width modulation (PWM) control. The carrier frequency is configurable, and for C-frame drives such as the 1336F-A020-AN-FR drive, it can be set at 2 to 6 kilohertz. The drive output rating of 20 Horsepower is valid for 4 kilohertz carrier frequency and 3-phase input voltage rated at 200 to 240 Volts AC. The 1336F-A020-AN-FR drive supports single-phase input too, but with 50% output derating. The 1336F-A020-AN-FR drive can operate in French. The drive enclosure is IP 00 rated and the drive weighs about 85 pounds. The drive dimensions are 701 millimeters in height, 301 millimeters in width, and 93.5 millimeters in depth. The Allen-Bradley 1336F-A020-AN-FR 1336 PLUS II drive is designed for vertical mounting inside a suitable control cabinet. The working temperature range is from 32 to 122 degrees Fahrenheit and the storage temperature range is from -40 to 158 degrees Fahrenheit. The drive can operate without derating at altitudes of up to 3300 feet. The permitted range for the ambient non-conde
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
