Product Overview
Product Overview
Allen-Bradley 1336F-AQF20-AA-EN-GMS5-L4 is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Enclosure: NEMA Type 1
Application & Compatibility
The Allen-Bradley 1336F-AQF20-AA-EN-GMS5-L4 1336 PLUS II series drive is a 2 Horsepower rated variable frequency drive. It works with AC or DC input voltage. The supported DC input voltage is 310 Volts DC. The supported AC input voltage is 200 to 240 Volts AC. For AC input, the 1336F-AQF20-AA-EN-GMS5-L4 drive supports single-phase and 3-phase power supplies. However, the full rated output power is only available with 3-phase AC input voltage, and only 50% of the rated output is available with single-phase AC input. The 1336F-AQF20-AA-EN-GMS5-L4 drive is designed for direct connection to AC power supplies and it does not include a built-in mechanism for protection against input short-circuits. An external input fuse or input circuit breaker can be used if necessary. The input current rating is 9.7 Amps and the output current rating is 8 Amps. The minimum and maximum ratings for the dual-element time-delay fuses are 10 Amps and 15 Amps, respectively and the minimum and maximum ratings for non-time delay fuses are 10 Amps and 20 Amps, respectively. The maximum current rating for a circuit breaker is 25 Amps and the maximum ratings for a motor circuit protector are 15 Amps. The Allen-B
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
