Product Overview
Product Overview
Allen-Bradley 1336F-AQF50-AN-EN-HCSP-L5 is a Adjustable Frequency Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: Adjustable Frequency Drive
Application & Compatibility
The Allen-Bradley 1336F-AQF50-AN-EN-HCSP-L5 adjustable frequency drive is a versatile 1336 PLUS II series drive. It can work with constant or variable torque. The PWM carrier frequency that this drive supports is also configurable and it can be set to values between 2 and 8 kilohertz. The nominal output power rating of 5 Horsepower or 3.7 kilowatts for this drive is specified for 4 kilohertz of rated carrier frequency. The ambient conditions that are required for proper drive operation include an ambient temperature range of 0 to 50 degrees Celsius temperature, 5 to 95% non-condensing relative humidity and a maximum operating altitude of 1000 meters above sea level. The 1336F-AQF50-AN-EN-HCSP-L5 drive can work at 310 Volts DC or 200 to 240 Volts AC of rated input voltage. The drive works with both single-phase and 3-phase AC input. However, the maximum nominal output power rating of the drive is only possible with 3-phase AC input voltage. The control interface on the 1336F-AQF50-AN-EN-HCSP-L5 drive operates at 24 Volts AC/DC. The menus on the HMI are all displayed in English. The HMI is located on the front of the drive and includes both a digital display screen and a keypad. The
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
