Product Overview
Product Overview
Allen-Bradley 1336F-B015-AA-EN-HAS1-LA2-LA3-L6 is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Power: 15 Horsepower
- Enclosure: NEMA
Application & Compatibility
The Allen-Bradley 1336F-B015-AA-EN-HAS1-LA2-LA3-L6 1336 PLUS II series drive is an adjustable frequency AC drive. The drive includes 2 slots for hosting optional analog interface modules. Slot A is used for analog interfaces on the drive and it features a pre-installed module that supports 2 isolated configurable inputs. Slot B on the drive also features a pre-installed module that supports 2 isolated configurable outputs. The control interfaces of the 1336F-B015-AA-EN-HAS1-LA2-LA3-L6 drive are rated for 115 Volts AC voltage. The drive itself is designed for 380 to 480 Volts AC input voltage (single-phase and 3-phase). The voltage tolerance is -10% of the minimum and +10% of the maximum voltage and the input frequency tolerance range is 47 to 63 Hertz. The input overvoltage threshold is 570 Volts AC and the input undervoltage threshold is 280 Volts AC. Depending on the drive rating of the Allen-Bradley 1336F-B015-AA-EN-HAS1-LA2-LA3-L6 1336 PLUS II series adjustable frequency AC drive, the hardware current limit ranges from 180 to 250% of the variable torque rated current and the instantaneous current limit can be set from 220 to 300% of the variable torque rated current. The 1336F-
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
