Product Overview
Product Overview
Allen-Bradley 1336F-B020-AA-EN-GM1-HAS2-LA7-L4 is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Power: 20 Horsepower
Application & Compatibility
The Allen-Bradley 1336F-B020-AA-EN-GM1-HAS2-LA7-L4 drive is an adjustable frequency drive from the 1336 PLUS II series. The output frequency range is from 0 to 400 Hertz, the output power rating is 20 Horsepower, and the output voltage range is 0 to the rated voltage. Additionally, the drive’s input voltage range is 380 to 480 Volts AC. Both single-phase and three-phase AC power supplies are supported. However, it should be noted that the output derates by 50% if single-phase AC power supplies are connected to the drive. The 1336F-B020-AA-EN-GM1-HAS2-LA7-L4 drive supports one isolated configurable input and one isolated bi-polar input on its analog interface. The 1336F-B020-AA-EN-GM1-HAS2-LA7-L4 adjustable frequency drive can be configured and monitored through its integrated HMI which includes a digital potentiometer. The menus on the drive HMI are displayed in English. The Allen-Bradley 1336F-B020-AA-EN-GM1-HAS2-LA7-L4 1336 PLUS II series adjustable frequency drive comes in a NEMA Type 1 protective enclosure. The ingress protection rating of the enclosure is IP20. This protection rating indicates that the drive is not protected against large quantities of water and dust. Theref
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
