Product Overview
Product Overview
Allen-Bradley 1336F-B020-AA-EN-HCS1-LA2-LA3-L6 is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Power: 20 Horsepower
- Enclosure: NEMA Type 1
Application & Compatibility
The 1336F-B020-AA-EN-HCS1-LA2-LA3-L6 drive is an Allen-Bradley 1336 PLUS II series adjustable frequency drive. This 1336 PLUS II series drive includes 2 slots for analog I/O modules. Both of these slots include pre-installed modules. Slot A has a module with 2 isolated configurable input channels. Slot B has a module with 2 isolated configurable output channels. The 1336F-B020-AA-EN-HCS1-LA2-LA3-L6 drive also supports a control interface that works at 115 Volts AC rated voltage. Additionally, an integrated HMI allows for easy drive configuration and monitoring. The key features of the HMI include an analog potentiometer, programmer/controller support, and application file upload/download capabilities. The 1336F-B020-AA-EN-HCS1-LA2-LA3-L6 drive operates at 380 to 480 Volts AC input voltage. An input protection feature shuts down the drive if the AC input rises to 570 Volts AC or falls to 280 Volts AC. The DC bus on the Allen-Bradley 1336F-B020-AA-EN-HCS1-LA2-LA3-L6 1336 PLUS II series adjustable frequency drive is rated for 648 Volts DC nominal voltage. There is an integrated protection function that shuts down the drive if the DC bus voltage rises to 810 Volts DC or falls to 400 Vo
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
