Product Overview
Product Overview
Allen-Bradley 1336F-B030-AN-EN-LA3-L6-MX3 is a Motor Control Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: Motor Control Drive
- Power: 30 Horsepower
Application & Compatibility
The Allen-Bradley 1336F-B030-AN-EN-LA3-L6-MX3 1336 PLUS II series drive is a motor control drive with an output power rating of 30 Horsepower. However, this output power rating is only valid for specified ambient conditions. Deviation from the specified ambient conditions will lead to output derating and possibly to drive damage. The output power rating of 30 Horsepower is only valid for 3-phase AC input voltage, and it derates by 50% with single-phase AC input voltage. The drive also needs to operate at temperatures between 32 and 122 degrees Fahrenheit to support 30 Horsepower of output. The elevation of the installation site also needs to be between 0 and 1000 meters above sea level and the PWM frequency rating must be 4 kilohertz. The 1336F-B030-AN-EN-LA3-L6-MX3 drive can operate at carrier frequency ratings from 2 to 8 kilohertz and the output voltage range for the drive is 0 to the rated voltage. The output frequency range of the Allen-Bradley 1336F-B030-AN-EN-LA3-L6-MX3 1336 PLUS II series motor control drive is 0 to 400 Hertz, the input voltage range is 380 to 480 Volts AC, and the input frequency range is 47 to 63 Hertz. This modular drive comes with 2 factory-installed ha
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
