Product Overview
Product Overview
Allen-Bradley 1336F-B030-AN-EN-LA3-LA6-L4 is a Motor Control Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: Motor Control Drive
- Power: 30 Horsepower, 22 Kilowatts
Application & Compatibility
The Allen-Bradley 1336F-B030-AN-EN-LA3-LA6-L4 drive from the 1336 PLUS II product line is rated for 380 to 480 Volts AC of 3-phase input voltage, for 22 kilowatts or 30 Horsepower of nominal output power, and for 97.5% maximum operating efficiency at the nominal line voltage and the rated current. The drive’s current rating can be proactively limited to reduce the chances of the drive tripping unexpectedly or unnecessarily, and its limit can be set at 20% to 160% of the drive’s rated output current value. The users of the 1336F-B030-AN-EN-LA3-LA6-L4 drive can control it through its built-in control interface that has a TTL contact option, and they can connect it to other equipment through the inputs and outputs that are built into it or through the inputs and outputs on its analog interfaces. The 1336F-B030-AN-EN-LA3-LA6-L4 drive has 2 slots for hosting analog interfaces and both of them are occupied by analog interface modules which allow it to be connected to more devices than it could connect to on its own. One of the analog interfaces on the Allen-Bradley 1336F-B030-AN-EN-LA3-LA6-L4 1336 PLUS II series drive has 2 isolated outputs. Both outputs can operate as voltage or cur
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
