Product Overview
Product Overview
Allen-Bradley 1336F-BRF100-AA-EN-HAS2-L8E is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Enclosure: IP20 (NEMA 1)
Application & Compatibility
The 1336F-BRF100-AA-EN-HAS2-L8E model from the Allen Bradley 1336 PLUS II Drives series serves as a versatile AC drive with significant specifications. It operates effectively with a rated voltage spanning from 380 to 480 volts AC or from 513 to 620 volts DC. This unit is compliant with standard 3-phase systems, supporting both 50 Hz and 60 Hz operation. It provides a current rating of 22.4A for voltage transformer input and 22A for output, ensuring adequate power flows in various applications. Functionally, this AC drive is designed with an impressive rated continuous transformer output power of 7.5 kW, translating to a horsepower rating of 10 HP. For voltage transformer output, it offers a rating of 11.2 kW or 15 HP, making it suitable for a range of demanding operational requirements. The drive is housed in an enclosure with an IP20 rating, classified as NEMA 1, providing essential protection against dust and accidental contact.
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
