Product Overview
Product Overview
Allen-Bradley 1336F-CWF10-AA-EN-HASP-L4 is a Industrial Component used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
Application & Compatibility
The 1.0 Horsepower-rated 1336F-CWF10-AA-EN-HASP-L4 drive is an Allen-Bradley 1336 PLUS II series adjustable frequency drive which complies with the following CE low voltage directives: the EN 60204-1 and the PREN 50178 directives. The 1336F-CWF10-AA-EN-HASP-L4 drive has constant torque capabilities and it operates at input voltages ranging from 500 to 600 Volts AC. The rated output power and current levels are 1.0 Horsepower (0.75 kilowatts) and 2 Amps, respectively. The input current rating is 2.4 Amps. The integrated human-machine interface is a programmer-only interface. Built-in control interface I/O on the drive support TTL contact. The overvoltage and undervoltage thresholds for the input side of the 1336F-CWF10-AA-EN-HASP-L4 drive are 690 Volts AC and 343 Volts AC, respectively. The nominal drive bus voltage value is 810 Volts DC. The drive bus is configured to trip at 1013 Volts DC and at 498 Volts DC, which are the configured bus overvoltage and undervoltage threshold settings. The A4-type drive frame weighs 35 pounds and it has the following dimensions: 350 x 260 x 117 millimeters. The enclosure of the drive is a NEMA Type 1 enclosure which is rated as an IP20 enclosure.
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
