Product Overview
Product Overview
Allen-Bradley 1336F-CWF20-AA-EN-HAS2-L5 is a Industrial Component used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
Application & Compatibility
The 2 Horsepower-rated Allen-Bradley 1336F-CWF20-AA-EN-HAS2-L5 AC drive is a 1336 PLUS II series AC drive. Designed to support 500 to 600 Volts AC input voltage, the 1336F-CWF20-AA-EN-HAS2-L5 delivers 2 Horsepower of output power and 4 Amps of current at its output in the constant torque mode. The input current is rated at 4.8 Amps. The drive also features an HMI with programmer/controller and digital potentiometer. The language supported by the HMI is English. The control interfaces provided on the 1336F-CWF20-AA-EN-HAS2-L5 drive support both 24 Volts DC/AC voltage. The rating of the circuit breaker which is recommended for use at the input to the 1336F-CWF20-AA-EN-HAS2-L5 is 15 Amps. Furthermore, fuses that can also be used at drive input include the dual-element time-delay fuse rated at a minimum of 6 Amps and the non-time delay fuse rated at a minimum of 6 Amps and at a maximum of 10 Amps. The recommended current rating of the 1336F-CWF20-AA-EN-HAS2-L5 AC drive’s motor circuit protector is 7 Amps (maximum). The drive input is set to trip at an overvoltage threshold of 690 Volts AC and at an undervoltage threshold of 343 Volts AC. Am instantaneous current limit can be set from
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
