Product Overview
Product Overview
Allen-Bradley 1336S-B200-AN-EN4-HA1-L6 is a Industrial Component used in industrial automation systems. It belongs to the 1336 PLUS Drives family.
Product Highlights
- Product Line: 1336 PLUS Drives
Application & Compatibility
The 1336S-B200-AN-EN4-HA1-L6 drive is an AC drive manufactured by Allen-Bradley. The drive belongs to the Allen-Bradley 1336S Plus family of AC drives. The 1336S-B200-AN-EN4-HA1-L6 drive has circuit boards (printed) and other components that are likely to contain harmful voltage levels. This calls for extra care when handling the drive, especially after it has been connected to the power supply. These precautions include waiting for the capacitors to discharge or manually discharging the capacitors before working on the drive. A successful discharge operation is measured by the bus voltage going down to zero when it is measured between +DC and –DC on terminal block 1, which is used for power connections. Note that the 1336S-B200-AN-EN4-HA1-L6 drive’s snubber capacitors may contain a voltage of up to 1,000 Volts DC. On these capacitors, a successful discharge operation can be measured across capacitors C2, C3, and C4. When discharging the snubber capacitors, a resistor greater than 1 ohm and less than 100 ohms, rated at 25 Watts minimum is required to discharge any voltage. Although an oscilloscope can be used to measure high-voltage waveforms, it can lead to fatal voltages if i
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
