Product Overview
Product Overview
Allen-Bradley 1336S-BRF07-AE-DE4 is a Industrial Component used in industrial automation systems. It belongs to the 1336 PLUS Drives family.
Product Highlights
- Product Line: 1336 PLUS Drives
Application & Compatibility
The 0.75 Horsepower-rated 1336S-BRF07-AE-DE4 drive is a 1336 PLUS series drive manufactured by Allen-Bradley. The nameplate on the A1-frame 1336S-BRF07-AE-DE4 drive can be found on the bottom portion of the drive chassis behind the cover. The 1336S-BRF07-AE-DE4 drive is designed to operate with 3-phase input voltages between 380 and 480 Volts AC. The input line frequencies supported by the drive are from 48 to 62 Hertz. The rated input current is 2.1 Amps in the variable torque mode and it is 2.0 Amps in the constant torque mode. The rated input power range is from 1.4 to 1.7 kVA in the variable torque mode and the range is from 1.3 to 1.6 kVA in the constant torque mode. The 1336S-BRF07-AE-DE4 drive’s full-rated drive output power is 0.75 Horsepower (0.56 kilowatts) and it is available only with 3-phase input. The full rated output current is 1.7 Amps in the variable torque mode and it is 1.6 Amps in the constant torque mode. The 1336S-BRF07-AE-DE4 drive supports single-phase input, but in this mode, the output derates and the drive is only able to deliver 50% of its rated current. The 1336S-BRF07-AE-DE4 drive supports input line protection which causes the drive to trip at pred
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
