Allen-Bradley 1336S-BRF07-AN-EN4 is a Industrial Component used in industrial automation systems. It belongs to the 1336 PLUS Drives family.
Product Highlights
- Product Line: 1336 PLUS Drives
Application & Compatibility
The 1336S-BRF07-AN-EN4 drive is a 0.75 Horsepower AC drive. It is part of the 1336 PLUS drive series from Allen-Bradley which supports the sensorless vector motor control algorithm. All of the 1336 PLUS drives support adjustable frequencies at the drive output. For an A1-frame drive like the 1336S-BRF07-AN-EN4 drive, the sine-coded PWM carrier frequency range is from 2 to 10 kilohertz and the output frequency range is from 0 to 400 Hertz. The drive input voltage range is from 380 to 480 Volts AC or 513 to 620 Volts DC. The drive output power rating is from 0.75 Horsepower or 0.56 kilowatts. The output current is 1.6 Amps in the constant torque mode and 1.7 Amps in the variable torque mode. The output ratings are based on 4 kilohertz of carrier frequency and 3-phase input voltage. The drive output derates when single-phase voltages are applied at the input or when the drive is installed at altitudes that exceed 1000 meters. The language module installed on the 1336S-BRF07-AN-EN4 drive is programmed in English. The IP 00 rated enclosure of the drive is open. The working temperature range for the drive is from 32 to 122 degrees Fahrenheit. The drive’s output frequency can vary from
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
