Product Overview
Product Overview
Technical specifications for 1492-AIFM16-F-3 Manufacturer Allen Bradley Product Type Fusible Analog Interface Module (IFM) Product Line 1492 Wiring System Part Number 1492-AIFM16-F-3 Weight 0.56 lbs (0.26 kg) UPC 662072009123 Channel Count 16 Input Channels Terminal Configuration Three Terminals per Channel Terminals per Channel Type Signal, Power/Shield, Common Protection Type Fusible (Individual circuit protection) Fuse Size Uses standard 5x20 mm fuses Indicator 24V DC Blown Fuse LED indicator for each channel Max Current per Circuit 2 Amps Max Current per Module 12 Amps Leakage Current (Blown Fuse) Approx 2mA (milliamps) (powers the LED) Operating Temperature 0 to 40 degrees Celsius Request a Repair Description The 1492-AIFM16-F-3 from Allen Bradley is categorized as a fusible analog interface module, part of the 1492 Wiring System. Engineered to accommodate 16 input channels, this module uses a versatile three-terminal configuration for each channel, distinguishing between power/sh
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
