Product Overview
Product Overview
Technical specifications for 1492-IFM20F-F120A-2 Manufacturer Allen Bradley Product Type Fusible Digital Interface Module (IFM) Product Line 1492 Wiring System Part Number 1492-IFM20F-F120A-2 Weight 0.69 lbs (0.31 kg) UPC 611320008654 Application Focus 120 volts AC Inputs Channel Count 16 Channels (Two groups of 8) Connector (PLC Side) 20-Pin Header (Male) Field Terminals 2 Terminals per Channel (Signal Input + Voltage Source) Nominal Voltage 120V AC Maximum Current per Circuit 2 Amps Max Current per Module 12 Amps Blown Fuse Indication Yes, 120V LED for each channel Wire Size AWG #22 to 12 (0.34 to 4 mm²) Certifications UL Listed, CSA Certified, CE Marked Request a Repair Description The fusible digital interface module, cataloged as 1492-IFM20F-F120A-2, belongs to the 1492 Wiring System by Allen Bradley. This device specializes in handling inputs of 120 volts AC and is equipped with 16 channels organized into two groups of 8. Each channel supports a total current of up to 2 Amps. Th
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
