Product Overview
Product Overview
Allen-Bradley 150-B97NBDB is a Motor controller used in industrial automation systems. It belongs to the SMC Dialog Plus family.
Product Highlights
- Product Line: SMC Dialog Plus
- Product Type: Motor controller
- Voltage: 200 to 460 Volts AC
- Enclosure: Open
Application & Compatibility
The Allen-Bradley 150-B97NBDB solid-state controller belongs to the Bulletin 150 SMC Dialog Plus series of motor controllers that support a voltage range of 200 to 600 Volts AC and that offer 1 to 1000 Amps of current at the output. The SMC Dialog Plus controllers are certified by the CSA, CE, and CCC standards and they also comply with the UL 508, EN/IEC 60947-1, and CSA C22.2 standards. The 150-B97NBDB controller is a 97 Amps rated motor controller with an open enclosure. The pump control is an optional motor control feature which is available as a standard feature on the 150-B97NBDB controller. Several other motor control options can be ordered from Allen-Bradley, including the preset slow speed and the accu stop. A total of six motor control modes are available on all SMC Dialog Plus controllers, including the current limit, dual ramp start, and energy saver modes. The output power range for the 150-B97NBDB controller is 5 to 500 Horsepower at 460 Volts AC. The controller can operate over a range of input voltages from 200 Volts AC to 460 Volts AC. Only three-phase input at 50 to 60 Hertz line frequency is supported. The control voltage range is 100 to 240 Volts AC. A 350 Amps
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
