Product Overview
Product Overview
Allen-Bradley 150-F361NBD is a Solid State Controller used in industrial automation systems. It belongs to the SMC-Flex family.
Product Highlights
- Product Line: SMC-Flex
- Product Type: Solid State Controller
Application & Compatibility
The 150-F25NBD Smart Motor Controller (SMC) is manufactured by Allen-Bradley for implementing an efficient starting, stopping and control of motors , preventing damage due to operating stress to maximize the motor’s operational hours and save energy by reducing and preventing unwanted and unnecessary electrical signals. It belongs to the microprocessor and solid-state component of SMC-Flex family of motor management devices which may also be . called as a soft starter. An adequate wiring must be applied to this device. Proper wiring ang torque application reduces overheating to the soft starter’s terminals. As this is a device rated for 361 Ampere Current output, the recommended Lug kit for use is 199-LG1 with wire strip length of 18-25 mm. The appropriate conductor size range is 25 to 240 sq. mm or #6 to 250 MCM. For line side, a maximum no. of Two (2) Lugs per pole. Similarly, the Load side requires the same. When tightening, applied Torque shall for wire-Lug shall be 42 Nm or 275 lb/in. For Lug-Busbar termination, tightness shall be 28 Nm or 250 lb/in.
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
