Technical specifications for 190S-CND2-DC20C Manufacturer Allen Bradley Product Type Thermal-magnetic trip block Product Line 190 Starters Part Number 190S-CND2-DC20C Weight 3.00 lbs (1.36 kg) Thermal Range 4–6 A adjustable Frequency 50–60 Hz Power Loss 14–23 W (typical) Short-circuit Capacity Up to 3–4.5 kA @ 690 V Making / Breaking ≈ 400 A AC Magnetic Range 50–80 A adjustable Short-trip Multiplier ~8.5–14 × thermal setpoint Thermal Accuracy ±5 % @ 40 °C; ±10 % @ 60 °C Magnetic Tolerance ±20 % Rated Insulation Voltage 690 V AC Continuous Current 42 A Protection Rating IP20 Mounting Position Any, ±30° vertical Terminal Capacity 1–16 mm² (single) Request a Repair Description The Allen Bradley 190S-CND2-DC20C is a thermal-magnetic trip block used for effective circuit protection. Capable of operating across a frequency range of 50 to 60 Hz, this trip block is desig
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
