Technical specifications for 2094-AC16-M03 Manufacturer Allen Bradley Category Drives Product Line Kinetix 6000 Part Number 2094-AC16-M03 Weight 11.94 lbs (5.41 kg) Module Type Axis Module Efficiency 0.95 Continuous Current (RMS) 17.3 Amps Continuous Current (0 to peak) 24.5 Amps Line Loss Ride Through 20 milliseconds AC input voltage 195 to 264 Volts AC Internal Shunt Continuous Power 200 Watts Internal Shunt Peak Power 5600 Watts Bus Overvoltage 425 Volts DC Shunt On 405 Volts DC View as PDF Request a Repair Description The Allen-Bradley 2094-AC16-M03 is a Kinetix 6000 multi-axis servo drive. It is also known as an IAM (Integrated Axis Module). The continuous output power of the module is 11.3 kW. On the top side of the unit, there is a connector for the power supply. Pins DC+ and DC- are used to connect a 325 Volts DC power supply. Pins L1, L2, and L3 are used for connecting a 3-phase 230 Volts AC power source. The digital I/O interface provides external devices with the possibility
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
