Product Overview
Product Overview
Allen-Bradley 20AD2P1A0AYNNENN is a Industrial Component used in industrial automation systems. It belongs to the PowerFlex 70 family.
Product Highlights
- Product Line: PowerFlex 70
- Frame: A
- Enclosure: Panel Mount - IP 20, NEMA/UL Type 1
Application & Compatibility
The Allen-Bradley 20AD2P1A0AYNNENN is an adjustable-frequency AC drive. Its output power rating is 1 Horsepower in normal duty mode at 480 Volts AC (3-phase, 50 Hertz) input. In the heavy-duty mode, its output power is 0.75 Horsepower. The output current is rated at 2.1 Amps when a 3-phase voltage is applied at the drive input. However, with single-phase input, the drive output derates to 50% of the rated current. The 20AD2P1A0AYNNENN is part of the Allen-Bradley PowerFlex 70 series. The 20AD2P1A0AYNNENN includes an integrated Ethernet port for network communication. The drive also includes a brake IGBT and it supports standard control. An HMI and a drive-mounted brake resistor are not included. Multiple optional brake resistors are available and they may be ordered as required. An optional HMI with multi-language support is also available. This optional HMI for the 20AD2P1A0AYNNENN includes a keypad for user input and an LCD for information and status display. The displacement power factor for the 20AD2P1A0AYNNENN is 0.98 and the drive efficiency is 97.5%. The maximum short-circuit rating is 200,000 Amps. The control method on the drive is a sine-coded PWM. The carrier frequency i
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
