Product Overview
Product Overview
Technical specifications for 505-DOD Manufacturer Allen Bradley Product Type Reversing Starter Product Line Bulletin 505 Part Number 505-DOD Weight 25.00 lbs (11.34 kg) UPC 781180217890 NEMA Rating NEMA Type 3 Maximum Operating Voltage 600 Volts AC Frequency Rating 50 to 60 Hertz Rated Phase 3-phase Nominal Coil Voltage 115 to 120 Volts AC Protection Type Open-type enclosure Rated Service Limit Current 104 Amperes Continuous Amperage 90 Amperes Mechanical Life Cycles Up to 5 million operations Type of Overload Relay Eutectic alloy relay Type of Mounting Surface mount Average Operating Time 37 milliseconds (pick-up), 20 milliseconds (drop-out) Circuit Closing Inrush Current 947 Amperes (maximum) Request a Repair Description The Allen Bradley 505-DOD is designed as a robust reversing starter for effective motor control. This component operates efficiently at a maximum voltage of 600 Volts AC and is rated for 3-phase operation. With a nominal coil voltage ranging from 115 to 120 Volts AC,
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
