Product Overview
Product Overview
Technical specifications for 509-CAA-1 Manufacturer Allen Bradley Product Type Non-Reversing Starter Product Line Bulletin 509 Part Number 509-CAA-1 Weight 10.00 lbs (4.54 kg) UPC 662072326572 Voltage 230-240V Size NEMA Size 2 Horsepower Rating 15 HP Phase 3-Phase Overload Protection Eutectic Overload Control START/STOP Push Button Indicator Incandescent Frequency 60Hz Continuous Current Rating 45 A Inrush Current 483 A Heat Dissipation 5.9 W Operating (Drop-Out) Time 13 ms Operating (Pick-Up) Time 27 ms Request a Repair Description The Allen Bradley 509-CAA-1 represents a non-reversing starter that excels in motor control applications. It is engineered to operate within a voltage range of 230-240 volts and meets the NEMA size 2 specifications for physical dimensions. This starter is compatible with three-phase electrical systems and has a horsepower rating of 15 HP, allowing it to manage substantial motor loads. Overload protection is provided through a eutectic overload design, ensur
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
