Product Overview
Product Overview
Technical specifications for 509-COD-9-90-900011 Manufacturer Allen Bradley Product Type NEMA Non-Reversing Starter Product Line Bulletin 509 Part Number 509-COD-9-90-900011 Weight 7.81 lbs (3.54 kg) UPC 885630201917 Voltage Rating 115/120V at 50/60 Hz Enclosure Open Type Non-Comb Starter NEMA Size 2 Current Rating 45A Contact Configuration 4 N.O. and 2 N.C. Material Eutectic Alloy Maximum Circuit-Closing Inrush Current 483 A Maximum Motor Horsepower 7.5 HP Coil Power Burden 38 VA Heat Dissipation (Power Loss) 5.9 W Operating Time (Pick-up) 27 ms Operating Time (Drop-out) 13 ms Power-Terminal Wire Size Range AWG 14 … AWG 4 Request a Repair Description Allen Bradley's 509-COD-9-90-900011 is a NEMA non-reversing starter specifically engineered for industrial applications. It operates efficiently at voltage ratings of 115/120 volts, adaptable for both 50 and 60 Hz frequencies. This starter adheres to the NEMA size 2 classification and is constructed with durable eutectic alloy materials
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
