Product Overview
Product Overview
Technical specifications for 74101-169-66 Manufacturer Allen Bradley Product Type Gate Drive Board Product Line 1336 PCB Boards Part Number 74101-169-66 Weight 6.19 lbs (2.81 kg) Rated Voltage 575 VAC HP Rating 200 Hp Input Signal Low-power control signals from the Main Control Board Output Function High-current drive pulses to the IGBT Min. Operating Temperature 0 degrees Celsius Max. Operating Temperature 40 degrees Celsius Min. Storage Temperature 0 degrees Celsius Max. Storage Temperature 40 degrees Celsius Operating Humidity 80% (non-condensing) Storage Humidity 80% (non-condensing) Installation Altitude 1000 m View as PDF Request a Repair Description The Allen Bradley 74101-169-66 is classified as a gate drive board and is part of the 1336 PCB Boards series. It is engineered for demanding motor control tasks that require high efficiency. This board operates at a rated voltage of 57
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
