Technical specifications for 845H-SJDZ24CNY2C Manufacturer Allen Bradley Product Type Incremental Encoder Product Line 845 Encoders Part Number 845H-SJDZ24CNY2C Weight 0.25 lbs (0.11 kg) UPC 662468380997 Supply Voltage 8–24 V DC Current Consumption 150 mA Response Frequency 210 kHz Maximum Shaft Speed 6000 RPM Resolution 5,000 PPR Output Drive Current ±20 mA Shaft Diameter 9.52 mm Starting Torque 2.5 N·cm Moment of Inertia 15 g·cm² Enclosure Rating NEMA Type 4 and 13 IP Rating IP66 Operating Temperature Range 0°C to 60°C Connector Type Radial connector Request a Repair Description The Allen Bradley 845H-SJDZ24CNY2C incremental encoder is designed for accuracy in motion control applications. It operates with a voltage input ranging from 8 to 24 volts DC, consuming 150 mA of current. This encoder achieves a resolution of 5,000 pulses per revolution (PPR), providing precise feedback in diverse settings. A notable feature includes its ability to respond to frequencies up to 210 kHz
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
