Technical specifications for 8520-1S5A-BAT-EX4-T1-Y-4-5-7 Manufacturer Allen Bradley Product Type 1 Axis Servo Drive Product Line 8520 CNC Controllers Part Number 8520-1S5A-BAT-EX4-T1-Y-4-5-7 Weight 25.00 lbs (11.34 kg) AC Input Voltage 380/460V ac AC Input Amps 15 max. AC Input VRMS 24 Short Circuit Current Amps 100,000 max. AC Input PH 3 AC Input Hz 50/60 DC Output KW 4/5 DC Output Voltage 5310/680V DC Output Amps 7.5 View as PDF Request a Repair Description The Allen-Bradley 8520-1S5A-BAT-EX4-T1-Y-4-5-7 is a Bulletin 8520 series 9 (9/440) 5kW 1-axis CNC drive system module. This device belongs to a 9/series family of computer numerical controllers (CNC). Its exclusive design allows the 8520-1S5A-BAT-EX4-T1-Y-4-5-7 to be used as an integrated motion controller and drive system. It integrates logic and servo controls into a single frame, thus removing wiring between the controller and drive and significantly reducing the footprint. The 8520-1S5A-BAT-EX4-T1-Y-4-5-7 Comes with a 32-bit
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
