Technical specifications for 8520-3APA1 Manufacturer Allen Bradley Product Type 3 Axis CNC Processor Board Product Line 8520 CNC Controllers Part Number 8520-3APA1 UPC 662453266749 Weight 2.00 lbs (0.91 kg) Output Voltage Range +/- 10V Output Offset Voltage 500mV max. Resolution 1.22mV Sampling Frequency 500Hz Output Current 5mA max. Conversion time 8.25 ms Gain Error +/-1 LSB max. View as PDF Request a Repair Description The Allen-Bradley 8520-3APA1 is the system module and the processor for the Allen-Bradley 9/440 3-axis CNC system. The 9/440 resolver–based CNC/Drive integrates a CNC module and a digital drive into 1 compact unit. This integration enables improved performance and at the same time leads to a reduction in cost, reduction in the time required for system integration, and reduction in the number of cables which are required to connect the various modules. The Allen-Bradley 9/440 3-axis CNC system can support 3 axis modules, 3 resolver feedback ports, and 2 analog output
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
