Technical specifications for 8520-AA6 Manufacturer Allen Bradley Product Type Servo Drive Amplifier Product Line 8520 CNC Controllers Part Number 8520-AA6 Weight 10.00 lbs (4.54 kg) Axes 2 Amps 6 Rated Current 6 A/axis Max. Output Current 12 A/axis External Input Power Source Fuse Rating 10A Main Circuit Input Power Source 3 Phase 170-253V ac 50/60 Hz Control Circuit Input Power Source Single Phase 170-253V ac 50/60 Hz Control Method Transistor PWM Control Dynamic Brake/Shunt Resistor Internal/External Ambient Temperature 0-55 C View as PDF Request a Repair Description The 8520-AA6 module is a servo amplifier manufactured by Allen-Bradley; it is a part of the 9 series CNC of amplifiers. Servo amplifiers are one of the main parts that servo motors utilize to improve general functioning. Servo motors are used to drive the axes of a machine; the task of the servo amplifier is to improve the amount of power delivered to the servo motor. It is also there to guarantee that the servomotor is
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
