Product Overview
Product Overview
Technical specifications for AN-X2-AB-DHRIO Manufacturer Allen Bradley Product Type Communication module Product Line ControlLogix Part Number AN-X2-AB-DHRIO Weight 0.69 lbs (0.31 kg) Description Network Connector Baud Rate 57.6 to 230.4 kbaud Supported Protocols Ethernet I/P; Remote I/O (RIO); Data Highway Plus (DH+) Rack Number 0 to 76 octal No. of Ports One (1) 10/100 mbps Ethernet I/P; One (1) Remote I/O (RIO) / Data Highway Plus (DH+) Power Consumption 200 milliamps Power supply 24 VDC Voltage 12 Volts DC Supported Ethernet devices ControlLogix; CompactLogix Current 100 milliamps Supported RIO / DH+ devices PLC, SLC 500, PanelView, Drives and Flex I/O Adapter modules Power Dissipation 2.4 Watts Mounting DIN Rail / Desktop RJ 45 Port Present No. of supported RIO modules 32 racks No. of supported drives Up to Four (4) Ethernet I/P drives No. of supported HMI Up to Eight (8) PanelView on the same network No. of supported Flex IO adapter No. of supported Flex IO adapter Operating Temp
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
