Product Overview
Product Overview
Technical specifications for MVI56E-MNETC Manufacturer Allen Bradley Product Type Modbus TCP/IP Multi Client/Server Enhanced Network Interface Module Product Line ControlLogix Part Number MVI56E-MNETC Weight 3.00 lbs (1.36 kg) Backplane Current Load 800 mA @ 5 V DC 3 mA @ 24 Vdc Module width Single slot Compatible rack ControlLogix chassis Data size 10,000 words, 16-bit registers Configuration Add-On-Instruction (AOI) ; Sample Ladder Compatible ControlLogix processor ControlLogix processor V 10 or higher No. clients 30 MODBUS TCP clients No. of servers 20 MODBUS TCP server Communication port One (1) RJ45 interface Data Rate 10 / 100 Mbps Operating Temperature 32° F to 140° F (0° C to 60° C) Storage Temperature ' -40° F to 185° F (-40° C to 85° C) Operating Shock 30 g Relative humidity 5% to 95% (without condensation) Slot(s) 1 Rack Type Local or Remote Data Transfer Type Ladder Logic Ethernet Configuration 10/100 Mbps User-definable Module Data Memory Mapping 10,000 Registers C
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
