Technical specifications for 3RG6114-3BF00 Manufacturer Siemens Product Type Sonar Sensor Product Line SIMATIC Part Number 3RG6114-3BF00 Weight 0.38 lbs (0.17 kg) Output Signal 4–20 mA Analog Switching Output Type PNP, 1 NO Housing Material Nickel-plated brass Operating Voltage 24 V DC Protection Rating IP65 Operating Current 300 mA max Mounting Type Fixed Connector Type M12, 5-pin Sensor Type Ultrasonic Sensing Range 600–6000 mm Signal Type Analog & Switching Output Mode Type G Request a Repair Description The Siemens 3RG6114-3BF00 is a precision sonar sensor designed for effective distance measurement in industrial settings. It operates using ultrasonic technology and is capable of sensing objects within a range of 600 to 6000 mm. An output signal of 4–20 mA is provided for analog applications, while a PNP-type switching output offers an additional normally open contact for flexibility in integration. A 24 V DC supply powers this sensor, with a maximum operating current of 300
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
