Technical specifications for 3RT1055-6AB36 Manufacturer Siemens Product Line SIRIUS Part Number 3RT1055-6AB36 UPC 754554771649 Weight 7.00 lbs (3.18 kg) Description of Module Power Contactor Coil Voltage 23–26 V AC/DC Coil Type AC/DC Number of Poles 3 Current Rating (AC-3) 150 A Power Rating 75 kW at 400 V AC Power Rating (HP) 60 HP at 230 V AC / 125 HP at 460 V AC Control Terminals Screw Terminals Main Circuit Connection Busbar Drive Type Conventional Ambient Temperature Range -25°C to +60°C Request a Repair Description The Siemens SIRIUS 3RT1055-6AB36 power contactor is designed for reliable performance in industrial environments. It accepts a coil voltage within the range of 23 to 26 V AC/DC and accommodates a conventional drive type. The unit features a robust current handling capacity of 150 A, catering to both high-voltage AC applications and DC solutions. This power contactor delivers a power rating of 75 kW when supplied at 400 V AC. At 230 V AC, it can manage up to 60 HP,
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
