Product Overview
Product Overview
Technical specifications for 3RT1064-6AF36 Manufacturer Siemens Product Line SIRIUS Part Number 3RT1064-6AF36 UPC 754554771090 Weight 6.38 lbs (2.89 kg) Product Power Contactor Size S10 Rated Operating Current at AC-1 at 400 V 275 A Rated Operating Current at AC-3 at 400 V 225 A Rated Operating Power at AC-3 at 400 V 110 kW Rated Operating Voltage Up to 690 V Control Supply Voltage 110-127 V AC/DC Coil Power Consumption Approximately 650 VA at 110 V AC Mechanical Service Life Approximately 10 million switching cycles Operating Temperature Range -25°C to +60°C Storage Temperature Range -55°C to +80°C Protection Class On the front: IP00; at terminals: IP00 Number of poles 3 Voltage phase three-phase Voltage type AC Request a Repair Description Siemens presents the 3RT1064-6AF36, a power contactor belonging to the SIRIUS series designed for robust DC and AC operation. This device, suitable for three-phase voltage systems, is rated for a significant operating current: 275 A under AC-1
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
