Product Overview
Product Overview
Technical specifications for 3RT1466-6AP36 Manufacturer Siemens Product Type 3RT14 Series Power Contactor Product Line SIRIUS Part Number 3RT1466-6AP36 UPC 754554773452 Weight 2.75 lbs (1.25 kg) Series Contactors AC-1 Operational Current Capacity 400 A (690 V, 40°C); 380 A (690 V, 55-60°C) Main Circuit Voltage Rating 690 V AC, 3-pole Control Circuit Voltage Range 220–240 V AC/DC (50-60 Hz), with 0.8–1.1 operating range factor Auxiliary Contact Configuration 2 Normally Open (NO) + 2 Normally Closed (NC) Power Dissipation at Rated Load 105.6 W (total), 35.2 W per pole Mechanical Durability 10 million switching cycles (standard) Surge Voltage Withstand 8 kV (main circuit), 6 kV (auxiliary circuit) Operating Temperature Range -25°C to +60°C (ambient) Main Circuit Connection Busbar (25 mm width, 6 mm thickness) for 70–240 mm² conductors Short-Circuit Protection Requirements gG fuses (500 A, 690 V, 100 kA) for main circuit coordination Insulation Voltage Rating 1000 V (main circui
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
