Product Overview
Product Overview
Technical specifications for 6AG1420-2UD31-1CA1 Manufacturer Siemens Product Type Low-voltage frequency converter Product Line MICROMASTER Part Number 6AG1420-2UD31-1CA1 Weight 12.00 lbs (5.44 kg) Rated Power 11 kW Input Voltage Range 380–480 V AC, three-phase (±10%) Mains Frequency 47 Hz to 63 Hz Output Frequency Range 0–650 Hz (factory limit of 550 Hz) Power Factor At least 0.95 Efficiency Between 96% and 97% Overload Capacity 1.5× nominal output current for up to 60 s (300 s duty cycle) Control Methods V/f with linear, quadratic, and multipoint options; Flux Current Control (FCC) Switching Frequency 2 kHz to 16 kHz (adjustable in 2 kHz increments) Setpoint Accuracy 0.01 Hz (digital control) Digital Inputs 3 configurable isolated inputs Protection Rating IP20 Operating Temperature Limits –10 °C to +50 °C Frame Size and Dimensions Frame C; approximately 245×185×195 mm; weight ~5.0 kg Request a Repair Description The Siemens MICROMASTER 6AG1420-2UD31-1CA1 serves as a reliab
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
