Product Overview
Product Overview
Technical specifications for 6EV3054-0CC Manufacturer Siemens Product Type DC–DC regulated power supply module Product Line SINUMERIK Part Number 6EV3054-0CC Weight 2.50 lbs (1.13 kg) Nominal Input Voltage 24 VDC Input Voltage Range 19–30 VDC Input Current 10 A Output Power Capacity 125 W Ripple & Noise 50 mV RMS Isolation 500 VDC Relative Humidity 5% to 95% non-condensing Operating Temperature 0 °C to +55 °C Storage Temperature -25 °C to +70 °C Cooling Passive convection Mounting Plug-in module IP Rating IP20 Request a Repair Description The 6EV3054-0CC from Siemens is a specialized DC–DC regulated power supply module ideal for applications requiring precise power management in the SINUMERIK series. It operates with a nominal input voltage of 24 VDC, allowing flexibility through an acceptable voltage range of 19 to 30 VDC. This external device can accommodate an input current of up to 10 A, making it capable of supporting demanding tasks requiring stable power. Retaining out
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
