Product Overview
Product Overview
Technical specifications for 6SE6400-3TD03-2CD0 Manufacturer Siemens Product Type Output filter (LC filter) Product Line MICROMASTER Part Number 6SE6400-3TD03-2CD0 UPC 783087730250 Weight 24.06 lbs (10.91 kg) Design Compact and modular design Voltage Rating 380–480V AC Number of Phases Input 3-phase Current Rating 32.6 amps at 40°C; 29.7 amps at 50°C Maximum Motor Feeder Cable Length 200 meters (Shielded); 300 meters (Unshielded) Degree of Protection IP20 Mounting Vertical Position Insulation Resistance Approx. 100 MΩ (mega-ohms) at 500 volts DC Operating Temperature -10 to 40 degrees Celsius Storage Temperature -25 to 70 degrees Celsius Certification CE and UL certified Request a Repair Description Siemens offers the 6SE6400-3TD03-2CD0, a specialized output filter within the MICROMASTER series. This particular filter utilizes a compact and modular design, ideal for installations where space is limited. It supports a voltage rating between 380 and 480 volts AC, designed to accommo
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
