Product Overview
Product Overview
Technical specifications for 6SE6430-2UD33-0DA0 Manufacturer Siemens Product Line MICROMASTER Part Number 6SE6430-2UD33-0DA0 UPC 783087661417 Weight 22.00 lbs (9.98 kg) Input Voltage 380–480V AC Phase Type 3-phase Output Power 30 kW Output Current 57 A Frequency Range 47-63 Hz Product AC drive HP Rating 40 HP Efficiency >95% Internal Filter Not included Operating Temperature 0°C to +40°C Storage Temperature -20°C to +65°C Humidity 5–95% Enclosure Type IP20 Length 400 mm Width 200 mm Request a Repair Description The 6SE6430-2UD33-0DA0 model from Siemens is a highly efficient AC drive in the MICROMASTER series. It operates on a 3-phase electrical supply, utilizing an input voltage range of 380 to 480 volts AC. The drive can provide up to 30 kW of output power, with an output current peaking at 57 A. Designed for varied applications, the operational frequency range is between 47 and 63 Hz, ensuring compatibility across numerous systems. With a horsepower capability of 40 HP, th
Condition
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
