Siemens 6SN1118-1NK00-0AA1 Resolver module (Refurbished)

Product Overview

Technical specifications for 6SN1118-1NK00-0AA1 Manufacturer Siemens Product Type Resolver module Product Line SIMODRIVE Part Number 6SN1118-1NK00-0AA1 EAN 4025515014188 Weight 2.00 lbs (0.91 kg) Number of Controlled Axis 2-axis Encoder Type Serial encoder Serial Interface Type RS232 and RS-485 ports Optional Interface Type PROFIBUS DP Ambient Operating Temperature 0 to 55°C (in a non-condensing environment) Storage Temperature -40 to 70°C (in a non-condensing environment) Encoder Limit Frequency 108 to 432 Hertz Encoder Resolution 4096/16348 pulses per revolution Maximum Cable Length 164.04 feet (50 meters) Excitation 4.3 root-mean-square voltage at 9.6 kilohertz Request a Repair Description The Siemens 6SN1118-1NK00-0AA1 resolver module facilitates control over two axes. It utilizes a serial encoder type and is compatible with RS232 and RS-485 communication ports for robust and efficient signaling. For enhanced connectivity options, the module also supports an optional PROFIBUS DP

Condition

This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
