Technical specifications for HLXD63B600 Manufacturer Siemens Product Type Circuit breaker Product Line SENTRON Part Number HLXD63B600 UPC 783643314955 Weight 18.00 lbs (8.16 kg) Frame Type L-Frame (LD Frame) Amperage Rating 600 Amps Number of Poles 3 Poles Maximum Voltage 600 VAC DC Voltage Rating 250 VDC (Standard) / 500 VDC (Series wired) Interrupting Rating at 480 volts 65 kA (kAIC) Trip Unit Type Thermal Magnetic (Interchangeable) Thermal Trip Fixed Magnetic Adjustable Instantaneous Trip Range Adjustable from 3000A to 6000 amps Terminals Lugs are typically not included Request a Repair Description The Siemens HLXD63B600 circuit breaker is an L-Frame device offering impressive capabilities. This product is rated for 600 amps, making it suitable for substantial current applications. With three poles, it effectively interrupts circuits within a maximum voltage of 600 VAC. The breaker also supports DC performance, rated at 250 VDC as standard or 500 VDC when series wired. It boasts a t
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
