Product Overview
Product Overview
Allen-Bradley 1336F-A007-AA-EN-HAS2-LA4-LA7-L6 is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Power: 7.5 Horsepower
- Enclosure: IP 20
Application & Compatibility
The Allen-Bradley 1336F-A007-AA-EN-HAS2-LA4-LA7-L6 drive is a 1336 Plus II series variable frequency drive. It operates when it is connected to an AC mains power source with a voltage range of 200 to 240 Volts AC. The drive is compatible with both 3-phase and single-phase input voltage. The maximum rated output power is only supported by the 3-phase AC input voltage. When 3-phase AC input voltage is used, the 1336F-A007-AA-EN-HAS2-LA4-LA7-L6 drive output is rated for 5.5 kilowatts or 7.5 Horsepower of maximum output power. When single-phase input is used, the drive output derates to 50% of the maximum rated output power value. The drive supports several analog interface options which include an interface with 1 isolated bi-polar input rated for +/-10 Volts or +/-20 milliamps and 1 isolated input or an interface with 1 isolated configurable output and input. The control interface option on the 1336F-A007-AA-EN-HAS2-LA4-LA7-L6 drive is rated for 115 Volts AC. The drive control method is the PWM control method. The PWM carrier frequency range for the Allen-Bradley 1336F-A007-AA-EN-HAS2-LA4-LA7-L6 1336 Plus II series drive is from 2 to 8 kilohertz. The drive ratings specified in the pr
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
