Product Overview
Product Overview
Allen-Bradley 1336F-A007-AN-EN-LA4-L6 is a AC Drive used in industrial automation systems. It belongs to the 1336 PLUS II Drives family.
Product Highlights
- Product Line: 1336 PLUS II Drives
- Product Type: AC Drive
- Power: 7.5 Horsepower
Application & Compatibility
The Allen-Bradley 1336F-A007-AN-EN-LA4-L6 1336 Plus II drive is an advanced type of adjustable frequency drive. It can operate in a constant torque mode and a variable torque mode. The electrical specifications for the drive include 200 to 240 Volts AC input voltage with 10% permitted input variation and 47 to 63 Hertz of frequency tolerance. Three-phase AC input voltage supports drive operation at its full ratings. Single-phase AC operation is supported too, but with 50% derating. The AC input overvoltage trip threshold is 285 Volts AC. The AC input undervoltage trip threshold is 138 Volts AC. The DC bus on the 1336F-A007-AN-EN-LA4-L6 drive has a nominal voltage rating of 324 Volts DC. The drive is set to trip at the bus undervoltage trip threshold of 200 Volts DC and at the bus overvoltage trip threshold of 405 Volts DC. The overcurrent trip has a hardware current limit of 180 to 225% of the variable torque rated current. The Allen-Bradley 1336F-A007-AN-EN-LA4-L6 1336 Plus II adjustable frequency drive can handle line transients of up to 6000 Volts according to the IEEE C62.41-1991 standards. The power ride-thru rating for the 1336F-A007-AN-EN-LA4-L6 drive is 15 milliseconds at a
Always verify the exact part number, electrical ratings, control options, and installed system compatibility before installation.
Condition: Refurbished
This unit has been professionally inspected, tested, and cleaned. Backed by a 2-Year warranty, it is fully functional and ready for industrial deployment.
