Product Overview
Product Overview
Technical specifications for 1386-M4 Manufacturer Allen Bradley Product Type 4-Axis DC Servo Unit Product Line 1386 Servo Drives Part Number 1386-M4 Weight 13.06 lbs (5.93 kg) Control Voltage 105–125 V AC, 50/60 Hz, single-phase Input Voltage Range 35 V / 78 V AC Input Phase Operates on 1- or 3-phase input DC Bus Output 50 V / 106 V DC nominal Continuous Current (1-Ph) 27 A Continuous Current (3-Ph) 50 A Peak Current (1 s) 50 A (1-ph) / 100 A (3-ph) DC Overvoltage Clamp Activates near 120 V DC Overvoltage Trip Cuts off around 130 V DC Regeneration Capacity 140 W energy return Control Supply Load Approx. 0.5 A draw Auxiliary Supply Output ±15 V DC, 1 A max Operating Temperature 0 – 50 °C Request a Repair Description The 1386-M4 from Allen Bradley is a sophisticated 4-axis DC servo unit designed for precision control in automation tasks. With a control voltage range of 105 to 125 vol
Condition
This item is new surplus inventory and has never been installed in an industrial environment. Original manufacturer packaging may not be available. The unit may show minor shelf wear from storage or handling. Backed by a 2-Year warranty, this component is ready for industrial use, spare inventory, system expansion, and replacement applications.
